FEATURES
Product features:
1. 24 and 48 total basals for selection
2. Big screen with backlight and simple list menu to use easily
3. Easy to operate
4. Powered by 1 AAA Alkaline battery, low expenses for patients
5. Available for all brands of infusion sets
6. Dual microprocessors for continuous cross checking to protect safety
7. Doctor Mode to care Patients
8. Auto lock screen to avoid operation mistakes
9. Auto reset for screw droved by motor from Swiss
10. Auto-calculate the filling insulin
11. Pulse infusion to improve the efficacy, whatever in basal or in bolus
12. Intelligent computerized system to memory the bolus settings which in the last morning, noon, and afternoon
13. Adjustable for the waiting time before the bolus
Detailed introduction
PH300 Insulin Pimp Technical Specification | |
Item | Parameter |
Range of application | The product is suitable for patients with diabetes who need insulin infusion therapy |
Size | 78mm×52mm×20mm |
Weight | 58g(Not included battery) |
CPU | Double CPU |
minimum dose | 0.05U |
Water Resistant | IPX8 |
Battery | 1 AAA alkaline battery |
Manu | Open type, some functions can be turned on or off freely |
Infusion method | Basal infusion, clinical-based infusion, high-dose infusion, square wave infusion |
Charging method | The screw is automatically reset, and the loaded amount of medicine is automatically calculated. |
Base rate segment | 24/48 basal rates |
Base rate setting step amount | 0.1U/0.05U |
Quick setting of base rate | 24-segment and 6-segment dual database |
Base rate settings | 0-5U(Or more) |
Base rate plan | 3 sets can be stored in advance |
Base rate calibration function | Yes |
Provisional base rate | Within 24hours, between 0-200%,10% increment or decrement |
High-dose setting mode | Regular mode and three-meal mode |
High-dose preset function | Yes |
High Dose Wizard Calculator | Yes |
Bolus infusion rate | Adjustable, 4 pulse periods:5s,10s,15s,20s |
Large dose setting increments | 0.1U |
High dose limit | 20u (default),Setting 0-85U |
Daily total limit | 60u (default),Setting 0-200U |
Daily total review record, Basal rate review record, High dose review record, Exhaust review record, alarm Review record | 50 |
Warning item | Obstruction, Low dose, drug out, low battery, Meal, Blood sugar measurement, Alarm |
Meal Tips | Can be opened, meal reminder 10min/20min/30min after high-dose infusion |
Blood sugar test tips | It can be turned on, and the blood sugar measurement prompt is 1h/2h/3h after high-dose infusion |
Alarm function | Yes |
Keyboard lock function | Yes |
Energy saving | Screen sleep mode |
Maximum charge | 305U |
Reservoir volume | 3.0mL |
Infusion line interface form | Luer interface |
Warning item parameters: | |
Low voltage | Low voltage prompt when the voltage is lower than 1.2V |
Low dose | When the liquid medicine is lower than 20U, the low liquid medicine prompt will be displayed. |
Drug out | When there is no infusion of liquid medicine, it will alarm when the medicine is finished |
Block | Blockage alarm before infusion line blockage reaches 6U |
Certifications
Our factory
Main markets
FAQ
Q: How does your factory do regarding quality control?
We have standard QC system to control the quality.
Q: Do you test all your goods before delivery?
Yes, we have 100% test before delivery.
Q: How can get the shipping cost?
You tell us your destination port or delivery address, we check the Sea Freight or Air Freight for you based on your requirement.
Q: Can you do OEM?
Yes, we can do OEM. We have complete facilities and more than 20 years experiences ready for your service.
Q: How long time warranty do you have?
We offer two-year warranty for the main unit and and accessories. And we have the professional service engineer to respond your service request within 24h.
Q: Whats your payment terms?
We accept payment by T/T, Western Union, Paypal, L/C, Trade Assurance etc.
Q: Is it certificated?
Yes, it is with CE certificated.
Q: Shipping way:
By express, by air, or by Sea
Q: Is it all right to make customers’own brand name?
That’s all right to make your own brand name.
